SHH-A Electric Chain Hoist (Fixed Type)

Home / Products / Electric Chain Hoist / SHH-A Electric Chain Hoist (Fixed Type)

SHH-A Electric Chain Hoist (Fixed Type)

PREV：TC Electric Chain HoistNEXT：No next article
  • Specification
  • About TBM
  • Contact Us
Model Capacity (t) Test load (t) Protection Working grade FEM/ISO Duty Cycle
(ED)		 Lifting speed (m/min) Lifting power (kW) Chain size (mm) Number of chain Net weight with standard 3-meter length(kg)
SHH-A003S1 0.25 0.32 IP55 3m/M6 50% 7 0.9 φ5x15 1 48
SHH-A003D1 33.4%/16.6% 7/2.3 0.9/0.3 61
SHH-A005S1 0.5 0.63 IP55 2m/M5 40% 7.6 0.9 φ6.3x19 1 49
SHH-A005D1 26.6%/13.4% 7.6/2.5 0.9/0.3 62
SHH-A010S1 1 1.25 IP55 2m/M5 40% 5 1.1 φ8x24 1 54
SHH-A010D1 26.6%/13.4% 5/1.7 1.1/0.37 63
SHH-A020S2 2 2.5 IP55 2m/M5 40% 2.5 1.1 φ8x24 2 64
SHH-A020D2 26.6%/13.4% 2.5/0.8 1.1/0.37 73
SHH-A030S1 3 3.75 IP55 2m/M5 40% 6 3.6 φ11.2x34 1 102
SHH-A030D1 26.6%/13.4% 6/2 3.6/1.2 124
SHH-A050S2 5 6.25 IP55 2m/M5 40% 3 3.6 φ11.2x34 2 124
SHH-A050D2 26.6%/13.4% 3/1 3.6/1.2 146
SHH-A075S3 7.5 9.38 IP55 1Am/M4 30% 2 3.6 φ11.2x34 3 206
SHH-A075D3 20%/10% 2/0.6 3.6/1.2 231
SHH-A100S4 10 12.5 IP55 1Am/M4 30% 3 3.6 φ11.2x34 4 282
SHH-A100D4 20%/10% 3/1 3.6/1.2 326
■ This product operates on a power supply voltage of 380V/50Hz/3P and a control voltage of 24V. For any modifications beyond those listed, please call for consultation.
