SHA8 Double Girder Electric Wire Rope Hoist(Double reel)-BZ Type

Home / Products / Electric Wire Rope Hoist / SHA8 Electric Wire Rope Hoist / SHA8 Double Girder Electric Wire Rope Hoist(Double reel)-BZ Type

SHA8 Double Girder Electric Wire Rope Hoist(Double reel)-BZ Type

Electric Wire Rope Hoist

SHA8 Double Girder Electric Wire Rope Hoist (Double reel)-BZ type adopts advanced electric hoist technology and double drum design, which can effectively improve the efficiency and safety of lifting operations. It is mainly composed of electric hoist, wire rope, double drum, drive trolley, etc. The design of this equipment fully considers the balance of load and the convenience of operation. The two drums operate at the same time to effectively share the load and avoid the motor overload caused by excessive load on a single drum. The double drum structure also effectively reduces the entanglement of wire ropes and extends the service life of wire ropes. The double-beam trolley structure optimizes the stability and operation convenience of the overall lifting equipment. The double-beam trolley is equipped with a high-strength pulley and wire rope system, which can provide better load balance and ensure a significant improvement in the safety of lifting operations. The double-beam structure also provides a larger span and better load capacity. This electric hoist is based on the collaboration of the electric drive system and the wire rope. The motor of the electric hoist drives the drum through the reducer, driving the wire rope to rise and fall around the drum to complete the lifting or lowering of the load.

PREV：SHA8 Double Girder Electric Wire Rope Hoist(Single Reel)-BS TypeNEXT：SHA8 Low-headroom Electric Wire Rope Hoist
  • Specification
  • About TBM
  • Contact Us
Model Capacity (L) Working Grade Working Grade Lifting Speed (m/min) Lifting Motor (kw) Travelling Speed (m/min) Travelling Motor (kw) Rad Gauge (S) A
(mm)		 B
(mm)		 C
(mm)		 D
(mm)		 Rail Width
（mm)		 Hmin
(mm)		 Wheel Diameter
（mm)		 Rope Diameter
（mm)		 Own Weight（kg)
6m 9m 12m
SHA8-41BZ 32 8/2 M5 4/0.6 2x16/2.6 20/5 2x1.5 2000 2000 2000 130 359 1100 75 60 660 250 18 3425
40 8/2 M4 4/0.6 2x16/2.6 20/5 2x1.5 2000 2000 2000 130 359 1100 75 60 660 250 18 3425
SHA8-5BZ 40 8/2 M5 3.4/0.5 2x16/2.6 20/5 2x2.2 2000 2000 2000 145 374 1150 85 70 760 315 18 3850
50 8/2 M4 3.4/0.5 2x16/2.6 20/5 2x2.2 2000 2000 2000 145 374 1150 85 70 760 315 18 3850
SHA8-6BZ 63 8/2 M4 6.5/1.1 2x38 20/5 2x3 2000 2000 2000 145 374 1280 85 70 820 315 20 4930
63 8/2 M5 4.9/0.8 2x38 20/5 2x3 2000 2000 2000 145 374 1330 85 70 840 315 20 5565
80 8/2 M4 4.9/0.8 2x38 20/5 2x4 2000 2000 2000 170 399 1330 95 80 840 400 20 5565
80 10/2 M5 4/0.6 2x38 20/5 2x4 2000 2000 2000 170 399 1330 95 80 930 400 20 6170
100 10/2 M4 4/0.6 2x38 20/5 2x4 2000 2000 2000 170 399 1330 95 80 930 400 20 6170
Zhejiang Shuangniao Lifting Equipment Co., Ltd. is a special equipment company specializing in the research and development, production, marketing and after-sales service of wire rope electric hoists. Since its establishment, the company has attached great importance to new product development and technological innovation, and has been focusing on high starting points and high configurations. In the research and development of electric hoist, while continuously introducing foreign advanced technology, it actively develops the research and development of new European-style electric hoist, and establishes the core concept of "innovation leads the future, focus on achieving wonderful", which has become the vane of domestic electric hoist development and leads The development of domestic electric hoist industry.
